AISI 304 Profile Wire Downhole Slotted Tube For Geothermal Wells

Name: AISI 304 Profile Wire Downhole Slotted Tube For Geothermal Wells
Brand: HengYuan
Price: 80 USD

Brand Name : HengYuan

Model Number : 89mm

Certification : ISO9001-2008

Place of Origin : Hebei ,China

MOQ : 10 pcs

Price : USD 80/pc

Payment Terms : L/C, T/T, Western Union

Supply Ability : 2000 pcs/month

Delivery Time : 7-10 days or based on the quantity

Packaging Details : wooden boxes or customized.

Name : Profile Wire Downhole Slotted Tube For Geothermal Wells

Material : AISI 304

O.D : 89mm

Slot : 0.25mm

Profile Wire : 1.5*2mm VEE wire

Support rod : 2*3mm VEE wire

Technique : all welding/ electric welding

Features : Non-clogging

Application : Geothermal Wells

Ends : Male/female threaded

Contact Now

AISI 304 Profile Wire Downhole Slotted Tube For Geothermal Wells

Profile Wire Downhole Slotted Tube, Is the Standard Construction features

external circumferential wire and internal support rods.

Profile Wire Downhole Slotted Tube also be named: Wire wrap screen, Wire wrapped screen pipe, Johnson Screen, Spiral screen tube, Welded wedge wire screen, Reversed slot screen, Continuous slot pre-pack, Water filter, Screen cylinders,Wound Screen, Stainless steel slot tube, Strainer pipe, Continuous slot wire wrap well screens, Stainless steel wire screen, Wire wrapped liner, Slot wire screen tube, Conical well screen, Suction strainers, Strainer screen wide slit screens, Well point screens, Oil screen tube.

Profile Wire Downhole Slotted Tube Advantages:

Non-clogging capabilities

Self supporting

High abreaction resistance

Large open area

Better sand filtration

Energy saving

Lowest possible cost

Long using life

Maximum flow capacity

Profile Wire Downhole Slotted Tube Normal Sizes:

Name	Profile Wire Downhole Slotted Tube For Geothermal Wells
Material	SS304, 316L,Deplex 2205, 2507 etc.
Diameter	29-1000mm
Length	1000-4000mm
Slot opening	0.1, 0.15, 0.2, 0.25, 0.3, 0.5, 1.0 mm etc
OD(mm)	29,32,38,40,42,45,48,50,53,57,58,60,65,68,70,76,80,82,89,100, 108,120,133,159,196,219,240,273,325,350,400,450,480,500,550,750,800,1000

AISI 304 Profile Wire Downhole Slotted Tube For Geothermal Wells
